T15-S DMX Dimmer | 1-Zone Touch Panel 100–240V LED Controller

Overview

The T15-S is a sleek, single-zone DMX master dimming controller designed for professional LED lighting systems. Powered directly from 100–240VAC, this touch-sensitive wall panel provides smooth dimming control through DMX512 output. With its minimalist interface and robust DMX performance, the T15-S is ideal for architectural lighting, hospitality spaces and commercial projects where a simple yet powerful dimming solution is required.

Key Features

• 1-zone precision dimming control
• DMX512 master output
• 100–240VAC direct power input
• Touch glass panel with illuminated interface
• Smooth 0–100% dimming performance
• Compatible with all DMX decoders and drivers
• Simple, elegant wall-mounted design
• Memory function restores last brightness level

DMX Control Functions

• DMX512 Output: Standard signal for single-channel LED applications
• Dimming Control: Adjust brightness from 0–100%
• Zone Control: Dedicated dimming for one lighting area

Technical Notes

• T15-S is a DMX master, requiring external DMX decoders.
• Suitable for monochrome LED strips, dimmable LED fixtures and architectural lighting.
• Ideal for areas where simple and reliable dimming is needed.
• Designed for indoor use in dry environments.

Applications

• Architectural LED lighting
• Hotels, restaurants and conference rooms
• Retail and showroom lighting
• Residential LED dimming control
• DMX-controlled cove or feature lighting
• Any single-zone installation requiring DMX dimming

Technical Specifications

Parameter	Specification
Model	T15-S
Zones	1 zone
Input Voltage	100–240VAC
Control Protocol	DMX512 (Master)
Control Type	Touch dimming (0–100%)
Interface	Capacitive touch glass panel
Mounting	Wall-mounted (AC wall box)
Compatible Devices	DMX decoders & DMX LED drivers
Environment	Indoor, dry locations
